FlushTop Sill Bolt Assembly
Cut-sheet and Components
Cross Sectional View - Not To Scale
Sill Bolt Options
Anchor Chair Type:
Coupler Options:
Depth of Concrete:
Threaded Rod Size:

Threaded rod meets ASTM A36/A307 specification.

ASB5P-S-ST-12

Assembly Components

ChubbyNubbi:  CBN5

Coupler Size: ASBC55G

Chaser: N/A

Rod Size:

Nut Size: N5

Base Chair: STRIPR

QTY Req'd
Project Name
Job #
SOID #
PO #
Computations:
Cut Rod = Conc. d. - ( Nub Ht. + 1/2 Cplr Ht. + Chr Ht. )
9.480 = 12 - ( 0.225 + 1.044 + 1.25 )
